D

B2D201 Pages: 2

6. Draw the figure of a smart phone which is both aesthetic and ergonomic.
7. Redesign the assembly given in the following figure based on the principles of design
for assembly and manufacture. Sketch the redesigned product.

8. Identify all the parts of a ceiling fan. List out the standard parts.

PART B
Answer any 2 questions. Ten marks for each question.
9. Disassemble the book shelf shown in figure ‘D’. Use the materials to make another
useful product. Show that the wastage of material is minimal.

Figure ‘D’

10. Modify a car for the use by a differently able person having only one leg.
11. Design a piping network for reuse of water in a residential building enabling water
conservation. Sketch the design.

%%%

Page 2 of 2
