the SFD and BMD. The bottom support is fixed and top support is roller.

ളു
൦൭൩

ದಾ

Fig 2
6 a) Define kinematic indeterminacy. Determine the kinematic indeterminacy of the (5)

following structures in Fig 3.

a. த்‌. த b. சு

५ ‏جسم‎

Fig.3
b) Analyse the truss shown in Fig. 4 (with active global coordinates, as shown) ஊம்‌ (10)
find the joint displacements, support reactions and bar forces. The truss is subjected
to direct loads Fl = 50 kN; F2 ಎ 30 kN, and a lack of fit due to bar AC being too
long by 5 mm. Assume all bars to have same axial rigidity AE = 6000 KN. Use

stiffness matrix method.

2
|
B — |
4

Fig 4 प्र ha
